Product Details

Manufacturer
Chauvet Lighting
Brand
Chauvet

Check All Offers Add to Wish List Customer Reviews

Features

  • Enhanced, brighter version of the popular Mini 4BAR(TM) with redesigned square pods
  • Increases flexibility by including: DMX control, master/slave capability, power linking and dual floor stands
  • Achieve total room or stage coverage with 4 individually adjustable heads
  • Set up almost anywhere with 1in deep, low-profile lights and tear down in seconds with the included tripod, carry bags and footswitch
  • Create coordinated light shows by linking other 4BAR(TM) and Mini 4BAR(TM) 2.0 fixtures in master/slave mode with sound-activated programs to dance to the beat of the music

Description

Mini 4BAR 2.0 is a ready-to-go, mobile wash system with four restyled, square LED wash lights, sporting 81 LEDs per pod, mounted on a bar with tripod, floor stands, footswitch controller and transport bags. In just five minutes this fixture can be set up and in use, plus each light can be positioned independently for maximum coverage. This versatility allows for the lights to crisscross or be aimed at different elevations for a multitude of effects.

Specifications:

• DMX Channels: 3 or 15
• DMX Connectors: 3-pin
• Light Source: 324 (108 red, 108 green, 108 blue) 0.25W (20mA) LEDs 100,000hrs
• Stand Height: 4.5 – 7.1ft (1.4 – 2.2m)
• Beam Angle: 16°
• Field Angle: 24°
• Illuminance: 558 lux @ 2m (per pod)
• Fits Tripod Sizes: 0.7 to 1in (19 to 24mm)
• Power Linking: 18 units @ 120V; 32 units @ 230V
• Input Voltage: Auto-ranging 100 – 240VAC 50/60Hz
• Power and Current: 52W, 0.4A @ 120V 60Hz
• Power and Current: 57W, 0.2A @ 230V 50Hz
• Weight: 8.2lbs (3.7kg)
• Size: 1.8 x 8.5 x 35in (46 x 215 x 889mm)
• Approvals: CE

Specifications subject to change without notice.
